Release Hand Parameters
| item | Robot Joint |
| Speed(RPM) | Custom |
| Continuous Current(A) | 3A |
| Efficiency | IE 1 |
| Warranty | 1 year |
| Rated Voltage | 12 V |
| Maximum torque | 10Nm |
| Place of Origin | China |
| Brand Name | Core Robot |
| Model Number | CR56 |
| Maximum speed | 25~60RPM |
| Rated Power | 1000W |
| Palm width | 80mm |
| Maximum hand width | 132mm |
| Hand length | 205mm |
| Finger length | 97mm |
| Force on the fingertips of the four fingers | 10N |
| Maximum force of the thumb | 12N |
| degree of freedom | 6 |
| Weight | 480g |
| Thumb transverse rotation range | 90° |
Core Robot’s mission is to empower customers with technology and provide customers with cost-effective robot hardware solutions. In the future, Core Robot hopes to promote the vigorous development of the artificial intelligence robot industry through continuous innovation and iteration of cutting-edge technology products, and work with partners to create a new era of automation and intelligence.
